Standard Features of Silicon Dry Cleaning Machine
1. Silicon, Hydrocarbon, or Modified Alcohol, either solvent is OK.
2. Available capacity 12kg
3. PLC controller with manual mode and automatic mode
4. Two Solvent Tanks for dark and light color separately
5. Special Carbon Filter with spin filter and lint filter.
6. Solvent Pallet to prevent solvent spill over out
7. Anti-corrosion 304 stainless steel drums, tanks, pipes, and components.
8. Optional fan cooling, no water is required for cooling.
9. Sterilization and disinfection function
10. Effecive drying with heat pump with volute chamber
11. Built-in steam generator for drying to protect the solvent from touching the heating element..
Optional Features for Silicon Dry Cleaning Machine
A. Distillation function for 12kg
B. Fan Cooling Unit, then no water is required for the whole process
C. If any customization is required, please feel free to let us know.
Specifications of Silicon Dry Cleaning Machine
| H608S | H612C | H616S | H620S | H625S | H630S | ||
| Capacity | kg | 8 | 12 | 16 | 20 | 25 | 30 |
| Drum Volume | lt | 145 | 215 | 285 | 350 | 440 | 560 |
| Washing Speed | rpm | 20-50 | 20-50 | 20-50 | 20-50 | 20-50 | 20-50 |
| Extracting Speed | rpm | 600-800 | 600-800 | 600-750 | 600-750 | 600-750 | 600-750 |
| Voltage | Vt | 220/380 | 380 | 380 | 380 | 380 | 380 |
| Total Power | kw | 9.7 | 12.7 | 18 | 18 | 25 | 25 |
| Compressed Air | mpa | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| Cooling Water | mpa | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 |
| Dimensions | mm | 1800*1250*2150 | 1800*1350*2150 | 2100*1350*2000 | 2100*1450*2000 | 2400*1350*2100 | 2400*1550*2100 |
| Net Weight | kg | 1000 | 1100 | 1500 | 1800 | 2100 | 2350 |
